Amina 50W @ 4Ohm Invisible Plaster-Over / Direct Adhesion Loudspeaker - Mobius 5


trade price available
Overview
Designed to be rendered invisible behind a 2mm skim of plaster, the Amina Mobius range of invisible loudspeakers push the sonic boundaries of what is possible with invisible loudspeaker technology.

Building on the award-winning Evolution Series design, Mobius series speakers incorporate OptiDrive and OptiDamping technology as well as Reduced-Resonance Exciter technology, offering greater low frequency extension and smooth high frequency dispersion all the way to the ultrasonic region. These developments allow for unprecedented high frequency performance and detail, enhanced bass reproduction and increased power handling, all in the easy to install, lightweight form-factor that Amina is known for.

Whether installed behind plaster, wood, synthetic veneer and many other materials, the Mobius series will allow for a great sounding, high fidelity audio system for any residential or high end commercial installation. Perfect for high quality distributed audio and multi-channel home cinema applications.

Technical Specifications

Product

Mobius 5

Nominal Impedance

4 Ohms (APUi50 connected)

Power Handling

50W/100W

Sensitivity

86dB 1m/2.83Vrms (APUi50 connected)

Frequency Response

65Hz - 30kHz (-6db) mounted in Backbox CV345 (APUi50 connected)

Electrical Connection

Blue butt-splice crimp terminals (14-16 AWG)

Dimensions

450mm x 345mm x 40mm (173/4” x 135/8” x 15/8”)

Product Weight

1.32Kg (2.9lbs)

Fixing Requirements

BackboxCV345 / BackboxSW345

In Line Protection Unit

APUi50

Rack-Mount Protection Unit

APURS8i or APURS16i


Warranty:
  • 1 Year (if Self-Installed)
  • 10 Years (if installed by SMH with In-Line or Rack-Mounted Protection Unit_

How to Video for Plaster installation


How to Video for Wood/Laminate Adhesion
  • Mobius Plaster Over Installation Guide : Download
  • Mobius Laminate / Wood Installation Guide : Download
£1,020.00 inc. VAT (1% Cashback available on all purchases via Debit Card)
£850.00 excl. VAT

Available for online purchase for Home delivery via Courier or Direct from Manufacturer/Distributor.
