Amina Back box for Mobius and Edge Series CV200 (Cavity Wall) (Slim-Line)


trade price available
 Description
The BackboxCV345 is an easy to install mounting option in plasterboard cavity walls (drywall) for Amina Invisible Loudspeakers with the dimensions 345mm x 450mm (Edge5,Edge7, Mobius5, Mobius7, MobiusDual).
The CV345 creates an acoustically tuned and consistent cavity behind the speaker, ensuring both consistent loudspeaker audio quality as well as minimising rearward airborne sound transmission.


  • Dimensions: H/W/D (mm) 500 x 206 x 71.5 aluminium back box
  • Use for installation of all 200mm width panels
  • Contains Composite sound proofing material
Technical Specifications

Product

BackboxCV200

Dimensions

500 x 204 x 71mm (1911/16 x81/32 x251/64”)

Product weight

1.2kg (2.65lbs)

Speaker cable entry

Rubber grommet (can be replaced by M20 gland)

Speaker fixing

Use 4x self tapping flangehead screws (supplied)

Wall Fixing

Use 8x self tapping drywall screws (supplied)

Minimum cavity depth

75mm (3”)

Sound pressure reduction

21dB on average over 150Hz - 5kHz range

£92.40 inc. VAT (1% Cashback available on all purchases via Debit Card)
£77.00 excl. VAT

Available for online purchase for Home delivery via Courier or Direct from Manufacturer/Distributor.
