Description
The CS140 in-ceiling model features a proprietary 4-inch mmp II cone and a pivoting version of our acclaimed c-cam Gold Dome tweeter. Engineered for excellent detail resolution and complete with either round or square grilles, the CS140 will deliver great sound with super-discreet aesthetics.
Please specify a round or square grille option when ordering.
Specification
Frequency Response: 75Hz - 30kHz
Power Handling (RMS): 50 W
Overall Size Round: 180.2mm (7 1/8”)
Overall Size Square: 176.7 x 176.7mm (6 15/16 x 6 15/16”)
Cable Connection: Gold plated ‘push’ type terminals
Pre-Construction Bracket: CB4 (Pink)
Impedance (nominal): 6 Ohms
Recommended Amp Requirements: 10 - 50 W
Mounting Depth: 98.6mm (3 7/8”)
Grille Attachment: Magnetic
Sensitivity (1W@1M): 85 dB
Drivers Unit Complement: 1 x 4”
mmp®II cone bass driver. 1 x 1” (25mm)
c-cam® pivoting gold dome tweeter
Cut-out Hole Diameter: 149mm (5 7/8”)
Construction Material: Mineral filled ABS, RoHS compliant
Maximum SPL (single unit in free space): 102.8 dBA
Acoustic Configuration: 2 way
Fixing Type: 3 position Tri-Grip® dog leg fixings
Weight: 1.18kg (2.6lb)
