WHAT IS IT?
Wireless 15 channel DMX controller for DMX controlled LED and other DMX light fixtures.
A 15 channel DMX controller for use with the Rako Rakom wireless network. Can be used to control DMX light fittings or interfaces such as colour changing LED drivers and fibre optic
Projectors.
In Control
Designed to be connected to the Rako Rakom wireless network and be controlled by any Rako wireless transmitter device such as the RCM wallplates or RA/RTC Bridges. The RSRDMX is addressed as a normal dimmer channel and automatically assigns the subsequent channels for DMX use.
DMX connections are available using either screw terminals or an RJ45 socket.
Technical Specification
Dimensions: 190x105x66mm
Input supply: 9-12v DC from SELV power supply unit (included)
Weight: 275g
Housing: UL V0 ABS
Climate range
Temperature: +2C to +40C
Humidity: +5% - 90% non-condensing
Connections: 3 way screw terminal or RJ45 cocket-dmx
Load Types: Any DMX512 compatible interface
Maximum Load: 15 DMX Channels
Standards
Emissions: EN61000-6-3 : 2001
Immunity: EN61000-6-1 : 2001
LVD: Any DMX512 compatible interface
Communication: Rakom coded fm radio, 433.9MHz
Memory: Flash memory (non volatile) Firmware upgrades via RASOFT programming
Software
Warranty: 2Year Return to Rako for Repair. Products older than 2 years can be repaired by Rako for a fixed fee of £50.
